12 Channel Relay RF Remote Control Switch Transmitter Receiver Module Wireless
1. Transmitter
Channel:12CH
Remote Control Distance:0-500m( Ideal Distance WITHOUT Any Block and Signal Interfere, Could Rise or Fall 10%-90% in Real Situation)
IC: SC/Pt/2260/2262/2264/ EV1527
Encode: 2260/2262/2264/ EV1527
Frequency:315 or 433.92
Size: 99mm x 78mm x 28mm
Power Supply: 1 X 12V/ or 24v
2. Receiver
- 1-12 Toggle/Self-Lock: Press->On; Press again->Off (Press key 1 to learn)
Press one button once the time is working/ON Press the same button again is stop/OFF. (press 1,1 relay works, press 1 again,1
relay stops working,2-12 works like this) - 1-12 Latched/Inter-Lock: Press->On; Press other button->Off (Press key 3 to learn)
Press one button is working/ON, press another button is stop/OFF.(press 1,1 relay works, press 2,1 relay stops working,2 relay
works,3-12 works like this) - 1-12 Momentary/Jog: Press and hold->On; Release->Off (Press key 2 to learn)
Keep pressing one button that is working /ON. loosen your finger is stop/OFF.(press 1 and hold,1 relay works,release key 1,1 relay
stops working,2-12 works like this) - 1-6 Toggle 7-12 Momentary (Press key 4 to learn)
- 1 Toggle 2-12 Momentary (Press key 5 to learn)
(The original Setting is Toggle, Change it by yourself.)
Decode: Learning code, soldering code
Power Supply (Operating Voltage): DC12V | 24V
Current:10mA
Sensitivity:ge-110dBm
Operating Temperature:-40lsquoC ~ 80rsquoC
Size:164mmⅹ89mmⅹ18mm
Frequency:315 / 433 MHz
Product Name: | DC 12V 12CH Channel10A RF Wireless Remote Control Switch System Transmitter and Receiver/lamp/Garage Door/shutters/ window |
Working Voltage: | Default: 12V | Optional: 24V |
Rated Power | ≤ 1000W |
Operating Frequency: | Default: 433Mhz |
Code Type: | Learning code |
Maximum Working Current: | 10A |
Modulation Mode: | ABS |
RF Sensitivity: | -110dBm |
Remote Distance: | 1000 m ( in space place ) |
Install way | Stiletto installation |
Installation Size | 100*46*16 mm |
Operating Temp: | -40C~+60C |
Battery Type: | 23 A 12V |
Application Scenarios: | Universal | Electronic Door | Auto Doors | Garage door | Rolling Door | Road Barrier | Motor |
Product Highlights | 1. Wireless control, easy to install. |
2. One/several transmitters can control one/several receivers simultaneously. | |
3. The wireless receiving controller, with high confidentiality, stable performance, low power consumption characteristic, jump line or dial the code switch coding. |
