Swing Gate Motors MR-SWGM200


Swing gate motors are available in various specification. the ultra modern motors secure the Residential, Apartment areas from outsiders the automatic magnetic lock, and Remote control made easy to operate the motor.

Swing Gate Motors MR-SWGM200

Motorized Swing gate motors are available in various specification. the ultra modern motors secure the Residential, Apartment areas from outsiders the automatic magnetic lock, and Remote control made easy to operate the motor.

NoticeIf you want to place an order, please contact the seller, we will calculate the cheapest freight for you!
500mm Sliding Block Arm Type Swing Gate Opener
Outside control box.
Mechanical limit switch.
Can choose one or two gates to open or close.
Assemble easily. In case of power failure, the gate can be opened and closed manually after releasing the clutch.

Specification:

ITEM  DESCRIPTION
Brand Name MRTECH
Model Number MR-SWGM200
Type Automatic Gate Operator
Name Swing Gate Motors
Material Aluminum & Plastic
Power Supply 220v / 110v
Max. Operating Current 4A for maximum 10 seconds
Max. Gate weight 200kg per leaf
Max gate length 2.5 meters
Operating Temperature -20ºc ∼ +50ºc
Duty Cycle 20%
Motor Weight 5.5 kg
MOQ 3 Set
Application Residentials, Apartments



Accessories Included With Swing Gate Motors Control Board with box, Remote Control, Voltage transformer, Rubber Bush, Manual key, and Wall Mount Kit.
Optional AccessoriesPhoto Sensor, Flashing Light, Bluetooth Controller, Wi-fi Mobile Access with ( Voice Command Through Google Assistant, Alexa, Siri ), RFID, Fingerprint, Vehicle LOOP Detectors, Face Recognition, Bluetooth USB Port.
Swing Gate Motors MR-SWGM200Swing Gate Motors MR-SWGM200Swing Gate Motors MR-SWGM200Swing Gate Motors MR-SWGM200
Swing Gate Motors MR-SWGM200
Swing Gate Motors MR-SWGM200

Technical Parameters of Control Board EG-22A

  1. Control Panel Voltage: AC 24V, available for 24 V backup battery.
  2. Applicable Range: Suitable for double arms swing gate opener.
  3. Encoder For Transmitter: Our own customized rolling code.
  4. Support Remote Control: Can memorize 120PCS transmitters at most
  5. Motor Character: 24V DC motor x2
Swing Gate Motors MR-SWGM200
Swing Gate Motors MR-SWGM200
Swing Gate Motors MR-SWGM200
Swing Gate Motors MR-SWGM200

Technical Specification:

 DC 24v Automatic swing gate opener
Model Number MR-SWGM200 MR-SWGM150
Power Supply 220v/110v 220v/110v
Motor Supply DC24v 40W*2 DC24v 40W*2
Max. Single leaf Weight 200KGS 150KGS
Max. Single leaf length 2.5M 2M
Rod’s running speed 1.6 cm/s 1.6 cm/s
Rotational Speed 250RPM 200RPM
Rod’s Max Travel 300mm 300mm
Protection Class IP55 IP55
NoticeIf you want to place an order, please contact the seller, we will calculate the cheapest freight for you!



ITEM  DESCRIPTION
Brand Name MRTECH
Model Number MR-SWGM200
Type Automatic Gate Operator
Name Swing Gate Motors
Material Aluminum & Plastic
Power Supply 220v / 110v
Max. Operating Current 4A for maximum 10 seconds
Max. Gate weight 200kg per leaf
Max gate length 2.5 meters
Operating Temperature -20ºc ∼ +50ºc
Duty Cycle 20%
Motor Weight 5.5 kg
MOQ 3 Set
Application Residentials, Apartments



Accessories Included With Automatic Swing Gate OperatorControl Board with box, Remote Control, Voltage transformer, Rubber Bush, Manual key, Wall Mount Kit.
Optional AccessoriesPhoto Sensor, Flashing Light, Bluetooth Controller, Wi-fi Mobile Access with ( Voice Command Through Google Assistant, Alexa, Siri ), RFID , Fingerprint, Vehicle LOOP Detectors, Face Recognition, Bluetooth USB Port.
