Gate Opener, Swing Gate Opener, Swing Gate Operator
Swing Gate Motors MR-SWGM200D
Motorized 200 kg Swing Gate operators are available in various specification and it can be customized according to customer needs and it is Manufacture with high featured technology.
Swing Gate Motors MR-SWGM200D
Motorized Swing gate motors are available in various specification. the ultra modern motors secure the Residential, Apartment areas from outsiders the automatic magnetic lock, and Remote control made easy to operate the motor.
| Notice | If you want to place an order, please contact the seller, we will calculate the cheapest freight for you! |
Advantage of Swing Gate Motors MR-SWGM200D:
- The Control panel can connect a flashing light, photocell, backup battery, solar system, keypad, and so on.
- Controlling single or double-leaf motor is optional.
- Can adjust open and close door time.
- 24V DC backup battery can be input. (this is use a large controller, our standard controller is small size.)
- The high-speed operation can be adjusted.
- Setting extra remote control is easy.
- Work with wifi device to operate the gate on Mobile Phone App.
This is the Swing Gate Motors MR-SWGM200D, which suits a lightweight gate and has the best competitive price.
Accept wifi receiver connect to make the gate opener can be controlled by mobile APP.
Accept camera connection to make the gate opener can be monitored and controlled by HOUSE mobile APP.
Digital LED swing board to make the all value set can be much correct. The software systems can be customized based on big quantity needs.
Offer the customized gate bracket for different install environment use.
Specification:
| ITEM | DESCRIPTION |
| Brand Name | MRTECH |
| Model Number | MR-SWGM200D |
| Type | Automatic Gate Operator |
| Name | Swing Gate Motors |
| Material | Aluminum & Plastic |
| Power Supply | 24V DC |
| Max. Operating Current | 4A for maximum 10 seconds |
| Max. Gate weight | 200kg per leaf |
| Max gate length | 2.5 meters |
| Operating Temperature | -20ºc ∼ +50ºc |
| Duty Cycle | 20% |
| Motor Weight | 5.5 kg |
| MOQ | 3 Set |
| Application | Residentials, Apartments |
| Accessories Included With Swing Gate Motors MR-SWGM200D | Control Board with box, Remote Control, Voltage transformer, Rubber Bush, Manual key, Wall Mount Kit. |
| Optional Accessories | Photo Sensor, Flashing Light, Bluetooth Controller, Wi-fi Mobile Access with ( Voice Command Through Google Assistant, Alexa, Siri ), RFID , Fingerprint, Vehicle LOOP Detectors, Face Recognition, Bluetooth USB Port. |
FEATURES of Swing Gate Motors MR-SWGM200D:
- swing gate opener Specification
- Driving Method: Screw Driven Piston Type
- Operating Voltage: DC 24V
- Operate the single gate width up to 3.5M
- Operate the single gate weight up to 300KG
- Waterproof IP55 design
- Adjustable Force
- Adjustable time-delay
- Manual Release
- Microprocessor-based control panel
- Working time protection
- Available to connect photocell, loop detector, card reader, backup battery, etc.
| ITEM | DESCRIPTION |
| Brand Name | MRTECH |
| Model Number | MR-SWGM200D |
| Type | Automatic Gate Operator |
| Name | Swing Gate Motors |
| Material | Aluminum & Plastic |
| Power Supply | 24V DC |
| Max. Operating Current | 4A for maximum 10 seconds |
| Max. Gate weight | 200kg per leaf |
| Max gate length | 2.5 meters |
| Operating Temperature | -20ºc ∼ +50ºc |
| Duty Cycle | 20% |
| Motor Weight | 5.5 kg |
| MOQ | 3 Set |
| Application | Residentials, Apartments |
| Notice | If you want to place an order, please contact the seller, we will calculate the cheapest freight for you! |
| Accessories Included With Swing Gate Motors MR-SWGM200D | Control Board with box, Remote Control, Voltage transformer, Rubber Bush, Manual key, Wall Mount Kit. |
| Optional Accessories | Photo Sensor, Flashing Light, Bluetooth Controller, Wi-fi Mobile Access with ( Voice Command Through Google Assistant, Alexa, Siri ), RFID , Fingerprint, Vehicle LOOP Detectors, Face Recognition, Bluetooth USB Port. |
