Electromagnetic Lock
Security System Electromagnetic Door Lock MR-EML350
The magnetic lock comes in variety of models to suit various entry and exit applications. Mounting brackets form an integral part in installation of magnetic locks to both in-swing and out-swing doors
Security System Electromagnetic Magnetic Door Lock MR-EML350
What is Electromagnetic Lock?
Electromagnetic Door Lock MR-EML350 consist of an armature and a coil assembly, which become magnetized when an electric current passes through them. This magnetic field secures the door and electronically controls when doors are locked and unlocked.
| Notice | If you want to place an order, please contact the seller, we will calculate the cheapest freight for you! |
Specification of Electromagnetic Door Lock MR-EML350:
| EM-350T | Without door position detection output |
| EM-350TS | With Signal output |
| Lock size | 194L x 34W x 23H (mm) |
| Armature plate | 132L x 34W x 12H (mm) |
| Working voltage | DC12V or DC24V |
| Current Draw | 12V / 480mA 24V / 240mA |
| Surface Temperature | ≤20ºC |
| Operating Temperature | -10ºC∼55ºC(14ºF – 131F) |
| Finishes for Shell | Anodized Aluminum |
| Finishes For Magnetic | Zinc |
| Finishes For Armature | Zinc |
| Weight | 1.5KG |
How Electromagnetic Locks be used?
An Electromagnetic Door Lock MR-EML350 is part of an entire security which may be connected to a keycard reader or to a complex system consisting of connections to central monitors that monitors the security of the premises.
It can be used for both in-swinging and out-swinging doors. For In-swinging doors, the lock is usually installed at the opening corner of the door. For out-swinging door the lock is usually installed on the side of the door header.
Security System Electromagnetic Door Lock MR-EML350 Advantages:
- Electromagnetic locks are fail-safe by design.
- Dual voltage selectable (12VDC or 24VDC)
- 304 stainless steel housing
- Epoxy-sealed electronics and weatherized for indoor and outdoor use
- Anti-Residual magnetism designed
- Low current consumption
- High-strength material, anodized aluminum housing
- Anti-residual magnetism designed
- Durable and silent operation
- CE Certificate by European Union
| Notice | If you want to place an order, please contact the seller, we will calculate the cheapest freight for you! |
| EM-350T | Without door position detection output |
| EM-350TS | With Signal output |
| Lock size | 194L x 34W x 23H (mm) |
| Armature plate | 132L x 34W x 12H (mm) |
| Working voltage | DC12V or DC24V |
| Current Draw | 12V / 480mA 24V / 240mA |
| Surface Temperature | ≤20ºC |
| Operating Temperature | -10ºC∼55ºC(14ºF – 131F) |
| Finishes for Shell | Anodized Aluminum |
| Finishes For Magnetic | Zinc |
| Finishes For Armature | Zinc |
| Weight | 1.5KG |
