MS Sliding Gate 35


Gates designed to operate in a very compact & space saving Best MS Sliding Gate Latest Design Price In Near me Cost-efficient designed and High durable material

MS Sliding Gate 35 with HPL sheet

Sliding Gate are very reliable and have long trouble-free lifespans. MS sliding gates with HPL sheet Occupy less Space as compared to swing gates. It maximizes space on the drive because the gate opens sideways rather than inwards. Preference for industrial, Commercial, and residential applications.

How Does an MS Sliding Gates work?

Tracked Sliding Gates run Along the Fixed track, upon which the majority of the gate’s weight is carried on wheels. The track is installed along the opening, running at the base of the gate, and the gate itself typically features automated operation

Sliding Gate Application

They are more secure and provide wide openings the ideal choice for industrial, commercial, and residential applications.

MS Sliding Gate Latest Design Price In Near Me

Customized Automated Gates designed and Fabrication in our Company. Electromechanically driven remote-controlled steel gates are hard and apt to be installed at any industrial, residential or commercial premises. The automatic gates safeguard long-term steadiness and exceptionally blends in with the style of buildings. Varied choice of models for gates weighing from 300Kg to 18000kg

Featured Product:

ItemDescription
MaterialMS steel, Mild Steel, Stainless Steel, Iron.
Customized DesignHPL Sheet, WPC Panel, ACP Sheet, Laser Cutting Design, etc.
Size Various type size Available Customer Requesting
ColorWhite, Black, Silver, and Costumer Requesting color are Available
Surface Treatment  Hot-Dip, Galvanized, Powder Coated.
Open StyleSliding gate
Optional openSliding-type, folding type, Bi-folding, Turning Sectional Sliding Gate, Cantilever Gate, Telescopic Gate, Retractable Gate.
Key WordsMain Iron Gate Designs
Drawing DesignAccording to Your request
Optional  productsAutomation, manual,  Semi-Automation, Voice cement System, fingerprint system,
ApplicationHouse, Industrial, commercial place, Warehouses

Hpl Sheet Colors Gate Design

HPL men High-Pressure Laminate Applications Solid color, Woodgrain, Marble(stone), Fancy, etc

Advantages of Automatic MS Sliding Gate

  • Planned and fabricated with superior square or rectangular hollow sections, along with MS sheets and flats collected by high-quality welding.
  • Manual operation in case of power failure.
  • Highly condensed dimensions & very silent operation. Built-in anti jerk device stops damage to the automatic system
  • Problem detection causes the gate movement to stop if a hindrance or person is detected
  • The advance electronic control unit licenses operation time adjustment, partial opening, reflex closing, step-by-step control, stop safety, reverse safety etc.

MS Sliding Gate Latest Design Price In Near Me

Variation of Track Sliding Gates

Track Sliding Gates: Gates made for light industrial applications where there is a wide entryway opening ( excess of 6 meters). They can be automated and also customized with various of infill, transparent or opaque relying upon site necessities. MS sliding gate offers better security than a Track Sliding Gates swing gate

MS Sliding Gate Latest Design Price In Near Me

Optional Sliding Gate Motor

Brand NameMRTECH
Motor VoltageDC 24V/AC230 V/AC 110V
Working systemS4-25%
Running Time10 min
Max. Gate Weight1.5 TON
Functions1. Soft Start and soft stop
2. Resistance Stop
3. Overload Protection
4. Infrared Protection
5. Reserve Power
6. Good self-hold performance
Limit SwitchSpring/Magnetic Limit Switch
ApplicationHouse, Office, Commercial
Dimension270*155*315mm
Gate Moving Speed14 m/min
Operating Temperature-45ºc ∼ +65ºc
Optional AccessoriesAlarm Lamp, Mounting Plate, Wireless Wall Button, etc

How to Concrete in the floor track?

Cut out and remove about a 150mm wide strip. Level the area with stone and compress. Lay the floor track in the trench and use the joining pins to join the lengths together. Level with a straight long edge and spirit level while aiming to keep the bubble of the level within the lines. On a loose substrate hammer small pins to either side of the track every 450mm. When it becomes tight weld it to the rack and cut off the excess. Lastly using Concrete, Backfill the top 13 ∼ 15 mm of the 20mm bar that’s Showing.

Troubleshooting Sliding Gates:

Troubleshooting the Sliding Gates if lock hangs up and does not latch properly try the following steps before contacting technical support

  • Reset closed position limit so gate is snug against stop plate
  • Lubricate latch with silicone spray to help latch to operate freely
ItemDescription
MaterialMS steel, Mild Steel, Stainless Steel, Iron.
Customized DesignHPL Sheet, WPC Panel, ACP Sheet, Laser Cutting Design, etc.
Size Various type size Available Customer Requesting
ColorWhite, Black, Silver, and Costumer Requesting color are Available
Surface Treatment  Hot-Dip, Galvanized, Powder Coated.
Open StyleSliding gate
Optional openSliding-type, folding type, Bi-folding, Turning Sectional Sliding Gate, Cantilever Gate, Telescopic Gate, Retractable Gate.
Key WordsMain Iron Gate Designs
Drawing DesignAccording to Your request
Optional  productsAutomation, manual,  Semi-Automation, Voice cement System, fingerprint system,
ApplicationHouse, Industrial, commercial place, Warehouses
Notice
If you want to place an order, please contact the seller, and we will calculate the cheapest freight for you!

Hpl Sheet Colors Gate Design

HPL men High-Pressure Laminate Applications Solid color, Woodgrain, Marble(stone), Fancy, etc
