Acrylic Double Wing Brushless DC 24V Motor Flap Barrier Turnstile Gate for School

Multi-lane Fast Flap Barrier Gate Swing Lane Access Control 304 Stainless Steel and Acrylic Double Wing Brushless DC 24V Motor Flap Barrier Turnstile Gate for School fitness centers or clubs

Quantity Price Discount
1-20 114,399.00 PIECE 0%
21-50 108,679.05 PIECE 5%
51-100 102,959.10 PIECE 10%
101+ 99,527.13 PIECE 13%
4 Items sold in last 2 minutes

114,399.00156,999.00PIECE

uiIvp8rjh5wAAAABJRU5ErkJggg== Double
Single
20wcWAMA37P6tkanUq6AAAAAASUVORK5CYII= Brushless

SEND US A MESSAGE

    CONTACT INFORMATION

    wd pointer

    Plot No 2, 4th St, Kailash Nagar, Tiruchirappalli,

    Tamil Nadu, India.

    Do you have questions about how we can help your company? Send us an email and we’ll get in touch shortly.

    product delivery 1 Add 35,000.00 and we will send you the order for free shipping!
    Ordered:3
    Items available:2
    product delivery 1

    Fast Shipping

    product meny products 1

    20k products

    product support 1

    24/7 Support

    product quality 1

    Delivery

    6473 People watching this product now!

    Description

    Acrylic Double Wing Brushless DC 24V Motor Flap Barrier Turnstile Gate for School

    precautions for use:

    In the process of using the sliding barrier turnstile, the passing personnel shall abide by the passing principle of “swiping card outside the yellow line or senseless identification, no trailing and reverse passing”. Note: pedestrians swipe their cards outside the yellow line on the outside of the passage. only the person can pass through a valid card at a time. It is forbidden for pedestrian behind to follow and  opposite to pass in the opposite direction without swiping their cards”. Pay attention to daily cleaning and maintenance during the use of the sliding barrier turnstile. Regular inspection can effectively prevent the aging of turnstile, the appearance and function can be customized according to the demand. Acrylic Double Wing Brushless DC 24V Motor Flap Barrier Turnstile Gate for School

    Acrylic Double Wing Brushless DC 24V Motor Flap Barrier Turnstile Gate for School

    Acrylic Double Wing Brushless DC 24V Motor Flap Barrier Turnstile Gate for School

    Product Technical Parameters

    Model NumberMR Y286
    size1400*300*1000mm
    MaterialSS304 grade stainless steel
    Thickness of materialbody cabinet 1.0mm, top of cover 1.2mm
    Arm materialAcrylic/Glass 10mm thickness
    Channel width ≤1000mm
    open gate signal inputDry contact signals, 232 or 485 commands.
    Unlocking time0.2s
    Speed of passage≤35p/Min
    Voltage input220V, 50H; (support adjustable)
    environmental temperature-25°C~+70°C
    working environmentIndoor/outdoor (under shade)
    MCBF≥5 million
    weightsingle core movement: 50KG / double core movement: 70KG
    configuarationone channel comes standard with 2 Astrometry air switches, 2 Meanwell switching power supplies, 2 motherboards, 2 super capacitors, and 6 pairs of infrared
    Driving MotorDC Servo motor or brushless motor: 24v/40w, 36v/200w, 24v/150w
    AlarmIllegal passage alarm, retrograde alarm, and standard alarm, can be linked to voice broadcasting, lights and other warnings, Mechanical anti-clamping, infrared anti-clamping, and anti-clamping with current:
    Advantages
    1. The equipment has a fault active feedback function, for gate failure, can actively upload fault code, realize the early warning, convenient maintenance
    2. Through the management computer to realize remote control door single pass open door, normally open, normally closed, fire control, return to normal and so on.
    Special Functions1. power failure open gate or power failure close gate is optional, default power failure open gate 6. Legal passage electronic booster pusher, illegal passage lock clutch. 2. support memory mode, automatic reset, free to set the passage time, support the passage of the completion of the feedback, the equipment can be set remotely more than 10 kinds of flexible configuration of the gate mode; 3. Equipment to support remote control of the pedestrian passage time settings, and real-time feedback settings; 4. Equipment to support the passage of the completion of the feedback, fault active feedback function for the gate failure, can actively upload the fault code, to achieve early warning, and easy maintenance; 5. Realize early warning and convenient maintenance; 6. Through the management computer to achieve remote control door single pass open door, multi-pass open door, normally open, normally closed, fire control, return to normal, etc.
    Secondary development
    1. tripod turnstile gates, 2w swing gates, wing gates, and speed gates have a unified secondary development interface, a docking, and can be connected to a variety of equipment;
    2. Can also provide the gate 485 development protocol, which has been encapsulated industrial control machine docking gate secondary development agreement(can provide RS485 protocol, windows API, Linux API

    Acrylic Double Wing Brushless DC 24V Motor Flap Barrier Turnstile Gate for School

    Acrylic Double Wing Brushless DC 24V Motor Flap Barrier Turnstile Gate for School



    Acrylic Double Wing Brushless DC 24V Motor Flap Barrier Turnstile Gate for School

    Acrylic Double Wing Brushless DC 24V Motor Flap Barrier Turnstile Gate for School

    Optional Access Control Solutions:

    The turnstile gate can work with RFID Card, QR code, Barcode, and ESD Tester. Thermometer Recognition, Face recognition, Fingerprint, Password Recognition, and other attendance device solutions.

    Occasion Application:

    suitable for commercial buildings, schools, GYM fitness centers or clubs, subways, airports, metro stations, IT Centre, offices, colleges, term parts, Supermarket, Railway stations, Library, Exhibition halls, government buildings, financial, industrial, University,  institutions, clubs, and other high-end places related to entrance access control solutions.
