Straight Arm DC Boom Barrier System MR-BB6D
The boom is typically mounted on a base that allows it to be raised and lowered to block or permit vehicles from passing through a designated area.
Straight Arm DC Boom Barrier System MR-BB6D
| Notice | If you want to place an order, please contact the seller, we will calculate the cheapest freight for you! |
Boom Barrier is a universal vehicular DC brushless barrier gate which carefully designed and unmanned manufactured for heavy traffic management and large commercial applications. Durable finishing, reliable brushless DC engine and multiple features make our barrier gates versatile solution for 24/7 use in heavy vehicle traffic flow
Specification:
| Brand | MRTECH |
| Model No | MR-BB6D |
| Product Name | Straight Arm DC Boom Barrier System |
| Voltage | DC24V |
| Current | 7.5A |
| Output Efficiency | 180W |
| Open/close time | 1.5∼6s adjustable |
| Motor rated speed | 780RPM (No load), 600RPM (Rated) |
| Operation Lifetime | ≥5 Million times |
| Temperature Range | -40ºC∼+75ºC |
| Boom Length | 3∼6 Meters |
| Gross Weight | 50 Kg |
| MOQ | 3set |
| Application | Hospitals, Shopping mall, Traffic Hub, Industrial Park, Government Buildings, etc. |
| Accessories Included With Boom Barrier | Control Board, Tension Spring, Remote Control, Manual key, Mounting Kit, Expansion Screws. |
| Optional Accessories | Photo Sensor, Flashing Light, Bluetooth Controller, Wi-fi Mobile Access with ( Voice Command Through Google Assistant, Alexa, Siri ), RFID , Vehicle LOOP Detectors, Face Recognition, Bluetooth USB Port. |
Performance Of Straight Arm Boom Barrier System:
- Fast and Smooth opening and closing ( speed is adjustable)
- Reliable 24V DC motor with link movement
- Designed for intensive use
- Auto reverse at any time if hits an obstruction
- Swing away mechanism will sheer off to prevent the barrier and boom arm ( for high speed arm barrier gate)
Advantages :
- Robust housing designed to protect the components, even when crashed by a vehicle.
- Straight Arm DC Boom Barrier System MR-BB6D has Maintenance free brushless motor, no need friction clutch.
- 24V DC brushless motor can get warming in cold climate when outside temperature is below 0, adapt to low temperature automatically.
- Precise mechanism and good heat dissipation will guarantee reliable and problem free operation in hot weather.
- 14 gauge zinc plated sheet steel with phosphate and powder coating finished for maximum protection against corrosion, and can be installed in any position without the risk of damage.
| Notice | If you want to place an order, please contact the seller, we will calculate the cheapest freight for you! |
| Brand | MRTECH |
| Model No | MR-BB6D |
| Product Name | Straight Arm DC Boom Barrier System |
| Voltage | DC24V |
| Current | 7.5A |
| Output Efficiency | 180W |
| Open/close time | 1.5∼6s adjustable |
| Motor rated speed | 780RPM (No load), 600RPM (Rated) |
| Operation Lifetime | ≥5 Million times |
| Temperature Range | -40ºC∼+75ºC |
| Boom Length | 3∼6 Meters |
| Gross Weight | 50 Kg |
| MOQ | 3set |
| Application | Hospitals, Shopping mall, Traffic Hub, Industrial Park, Government Buildings, etc. |
| Accessories Included With Boom Barrier | Control Board, Tension Spring, Remote Control, Manual key, Mounting Kit, Expansion Screws. |
| Optional Accessories | Photo Sensor, Flashing Light, Bluetooth Controller, Wi-fi Mobile Access with ( Voice Command Through Google Assistant, Alexa, Siri ), RFID , Vehicle LOOP Detectors, Face Recognition, Bluetooth USB Port. |
