Rolling Shutter Center Motor MRTRS-260
Rolling shutter is commonly used for garages, godowns, shops, etc. as they are quite strong and offer proper safety to the property.
Features
- The motor is Not visible.
- use a safety spring.
- Manual Operation all-time Thermal Protection.
- Built-in Speed Reducer
- Limit switch
- Digital Lock Remote Control
- Electro Magnetic Lock ( optional )
Shutter Center Motor is used in Rolling Shutters up to 6m x 6m. It can be Operated by remote control and ordinary switch. During Power fail, it allows operating the rolling by hand.
Fitted at the center of spring system suitable for up to 260 kgs Rolling Shutter Manual Operation on power fail clutch key for locking ( optional ) 100% safety due to spring system remote control ( optional )
Application
Shutter Center Motor used in Residence, Apartments, warehouses, Hotel, Banks,….etc upto ( 260 kgs )
Specification:
| ITEMÂ | DESCRIPTION |
| Brand Name | MR. TECH |
| Model Number | MRTRS- 260 |
| Type | Automatic Door Operator |
| Name | Door Operator |
| Usage | Garage Shutter Door |
| Material | Aluminum alloy |
| Voltage | 110/220V |
| Torque | 260N.m |
| R.P.M | 10 |
| Limit Switch | 6m |
| Power | 800w |
| Consumption | 3.48A |
| Motor Weight | 12KG |
| Tube Rolling | 60mm |
| Pulley | 200mm/220mm |
| Max. Shutter Weights | 260KGS |
| MOQ | 3 Set |
| Application | Villa, Residentials, Commercials |
Motorized Roller Shutters:
A very popular choice, Rolling Shutter is controlled by a Shutter Center Motor that opens and closes with the push of a button. These shutters can be operated by remote control or with a wall-mounted control panel.
- Easy to open and shut.
- Ideal for homeowners who find manual shutters hard to open and close.
- Durable, Offering secure protection from the elements and would-be intruders.
- can be programmed to open & close at particular times of the day.
- can be controlled remotely.
| Accessories Included With MOTOR | Control Board With Remote, Manual Release Break System, Flexible Cable, Electro Brake, Limit Switch, Brake Lining. |
| Optional Accessories | Bluetooth Controller, Wi-fi Mobile Access with ( Voice Command Through Google Assistant, Alexa, Siri ), RFID, Fingerprint, Vehicle LOOP Detectors, and Face Recognition. |
Technical Parameters
| Torque
(Nm) |
R.P.M
|
Limit Switch
(m) |
Running Time
(min) |
Power Absorbed
(w) |
Consumption
(A) |
Lifting
(KGS) |
Shutter Shaft Diameter (insert)
(mm) |
Flange/Drum Diameter
(mm) |
| 120 | 10 | 6 | 4 | 396 | 1.72 | 120 | 60mm(48mm) | Â 200mm/200mm |
| 140 | 10 | 6 | 4 | 450 | 1.95 | 140 | 60mm(48mm) | Â 200mm/200mm |
| 160 | 10 | 6 | 4 | 510 | 2.21 | 160 | 60mm(48mm) | Â 200mm/200mm |
| 180 | 10 | 6 | 4 | 590 | 2.56 | 180 | 60mm(48mm) | Â 200mm/200mm |
| 200 | 10 | 6 | 4 | 620 | 2.68 | 200 | 60mm(48mm) | Â 200mm/200mm |
| 240 | 10 | 6 | 4 | 725 | 3.15 | 240 | 60mm(48mm) | Â 200mm/200mm |
| 260 | 10 | 6 | 4 | 800 | 3.48 | 260 | 60mm(48mm) | Â 200mm/200mm |
| 360 | 10 | 6 | 4 | 880 | 3.64 | 360 | 60mm(48mm) | Â 200mm/200mm |
| 420 | 9.5 | 6 | 4 | 970 | 3.95 | 420 | 76mm(60mm) | Â 240mm/260mm |
Automatic Rolling Shutter Motor:
owing to the presence of our expert team members, we have been able to offer a wide range of Shutter Center Motor. These are available with us in various technical specifications and ranges as per the precise demands and requirements of clients. Our finely designed devices are available in various ranges and models
Advantages of Roller Shutter Center Motors:
- Secure: Roller Shutter doors are made of strong metals like steel and aluminum. This makes roller shutters robust and durable, which is the perfect deterrent against thieves.
- Fire Protection: Shutter Center Motor can help slow the spread of fires. What’s more, some roller shutters come with a fire-protecting rating, which means the shutter is built to withstand a fire for a certain amount of time
- Easy to operate: Most Roller shutter doors operate electrically, making them easy to open and close. It’s as simple as the push of a button.
- Rust and scratch protection: Roller Shutters often have special coatings to prevent rust and scratches. And if you find any rust or damage, then you can just re-paint the shutters to continue using them for a long time.
- Insulation: offer insulation benefits. Not only do they block out noise to an extent, but they can also help to keep your property warm in the winter and cool in the summer. This can help cut your electricity and gas bills too
- Customizable: We know your company’s brand is important. That’s why you can choose from a wide range of colors with our in-house powder coating service. What’s more, Powder coating makes our shutters stronger, more durable and more durable and more resistant to scratches, chipping, and corrosion.
