Roller shutters are fitted on the inside of your building. They are versatile and let in a lot of light. Moreover, interior roller shutters provide excellent ventilation. They look great from the outside of your home or building and come in several styles to suit your preferences. Our polycarbonate shutters have in-built high-performance drives and intelligent smart controls
Introduction
The most popular and widely used amongst all the categories of doors is the Clear Roller Shutter Doors The symbolic feature of our Transparent Rolling Shutter is its robust structure obtained due to the use of high-strength metals in the making of slate and guide profile. This feature acts as a shield and protection against burglary, vandalism & storms.
On one hand, these shutters require low maintenance, enabling very little inspection & manual attention, then on the other hand, our Clear Polycarbonate Shutter has very easy operation, ensuring total customer satisfaction. All these features are developed with vast years of experience in the manufacturing of rolling shutters; we can be stated as one of the oldest and most trusted names in the manufacture of high-grade and high-performance rolling shutters.
Our Clear Polycarbonate Shutter is manufactured in our state-of-the-art manufacturing facility, and the plant has a capacity to produce 500 rolling shutters in a month. Due to in-house designing and manufacturing, these Transparent Rolling Shutter are simple and robust. The products are featured with a door curtain that winds up very tightly and is suitable for a wide range of applications. Whether they are installed outside or inside, laterally or overhead, due to reduced space, motorised rolling shutters are suitable for any structural situation.
Specification:
Technical Specification | Description | ||
Product | Automatic Polycarbonate Shutter | ||
Brand | MR. TECH | ||
Model No | MR PCRS12 | ||
Application | Hospitals, Pharmaceutical, Aircraft, Shipyards, Food industries, Retail & Mall, Automobiles, Engineering, Logistics, Villa Residency, Chemical Industries, Educational Institutions | ||
Optional products | Manual, Semi-Automation, Automatic. | ||
Door Dimension | |||
Width Min./Max. | 1000/3000mm | ||
Height Min./Max. | 1000/5000mm Max. Area 15.0Sqm Large dimensions on request | ||
Mounting Location | Vertical | ||
Heat Insulation | Inside | ||
Mounting Surface | Concrete, Steel | ||
Opening/Closing Speed | 0.05m-0.1m/sec | ||
Door Structure | |||
Slat Material | Polycarbonate (3 mm thick) | ||
Slat Profile | Flat profile interlocked by SS-linked rods. | ||
Side Guide Profile | Aluminium profile with Rubber inserts on both ends. | ||
Bottom Profile | Aluminium profile with Bottom Rubber sealing | ||
Side Brackets | M.S plate 3mm to 10mm, as per the opening dimension | ||
Surface Finish | Standard Off White Color Special Color on request | ||
Details for Automation System | |||
Control Type | Casing made of compact impact-resistant material, incorporating operating buttons for shutter operation. Specific IP rating provided as per the requirement. Deadman / Pulse Control suggested application-wise. | ||
Drive Type | Imported make Indirect/Direct Connecting Drive selection made depending on the space opening availability, no of operations subjected etc. Drive with integral braking system with Long life expectancy, CE Certified drives complying with European standard | ||
Drive Unit | Electric Motor(Imported Make) Single Phase/Three Phase | ||
Emergency Operation | Manual operation by Hand chain or hand crank | ||
Protection Class | IP44/IP54 | ||
Accessories (Optional) can be integrated with advanced control |
|
Features
- MRM TECHNOLOGY EXIM transparent polycarbonate rolling shutters are constructed from interlocking polycarbonate slats.
- Suitable for internal applications where aesthetics are more focused
- These slats are provided with an SS rod, which gives strength to the shutter.
- Specially designed heavy-duty Extruded Aluminium Bottom profile
- Finger-tip control to open and close shutters of any size with the utmost ease from a single push-button switch or a radio remote control transmitter
- Our shutters have built-in high-performance drives and intelligent, smart controls
- Heavy-duty drives have a weight carrying capacity up to 2000 kg.
- In case of power failure, shutters can be operated manually using a hand crank or chain drive
- Shutter drives are inbuilt with a special anti-drop device and an additional safety catch to ensure that the door does not free-fall in any worst conditions
Optional Accessories | Photo Sensor, Flashing Light, Bluetooth Controller, Wi-fi Mobile Access with ( Voice Command Through Google Assistant, Alexa, Siri ), RFID, Vehicle LOOP Detectors, Face Recognition, Bluetooth USB Port. |
Motorized Polycarbonate Shutters Features:
- Longer product life, Fade proof.
- Glass like transparent but stronger in material.
- These rolling shutters can be used as both external and internal doors.
- High-level protection.
- We can customize it as per client requirements.
