Tripod Turnstile Access Control System

Anti-alarm is our standard request our access control system like rfid cards Tripod Turnstile Access Control System

Quantity Price Discount
1-5  96,540.00 Pieces 0%
6-15  92,678.40 Pieces 4%
16-50  87,851.40 Pieces 9%
51+  96,540.00 Pieces  0.00
2 Items sold in last 2 hours

Original price was: ₹ 106,948.00.Current price is: ₹ 96,540.00.Pieces

4 in stock

4 in stock



    wd pointer

    Plot No 2, 4th St, Kailash Nagar, Tiruchirappalli,

    Tamil Nadu, India.

    Do you have questions about how we can help your company? Send us an email and we’ll get in touch shortly.

    product delivery 1 Add  31,850.00 and we will send you the order for free shipping!
    Items available:4
    product delivery 1

    Fast Shipping

    product meny products 1

    20k products

    product support 1

    24/7 Support

    product quality 1


    7476 People watching this product now!

    Payment Methods:



    Tripod Turnstile Access Control System

    Tripod Turnstile Access Control System is a controlling device. Which designed for pedestrian access control. It is used in gymnasium, tourist attractions, factory, train, station, and so on. Indoor and outdoor, Tripod tripod turnstile gate price is a most effective-cost way to control pedestrian access. high reliability.

    Tripod Turnstile Access Control System

    Tripod Turnstile Gate Mechanism Features:

    1. The turnstile is intended for facilities with high traffic capacity: stadiums, universal sports complexes, exhibition centers, concert halls, cultural and educational institutions, transport facilities, etc.
    2.  Full-featured integrated access control software;
    3.  The integrated reader is designed to read contactless cards and all types of barcodes;
    4.  The interactive screen supports graffic and video display;
    5.  Convenient and user friendly management interface + API for connecting an external ACS;
    6.  High capacity. Instant triggering when a card or ticket is presented;
    7.  A two-way intelligent light display module shows the direction of passage and ticket category;
    8.  A patended unique anti-panic system-when alarm is triggered, the arms move to the lower position, therby ensuring an unobstructed passage;
    9.  A dapted to work in extreme conditions. Outdoor operation is possible both in the conditions of the Siberian winter and the heat, humidity and dust of Qatar.

    Tripod Turnstile Access Control System

    1. Advantage:

    The electric control adopts DC motor to drive stable and reliable, and has low failure rate. with ultra high light traffic indicator.

    2. Remind function:

    In the case of a man who does not swipe the card, the alarm will prompt the traveler to swipe card.

    3. Alarm Function:

    When a pedestrian swipes the card, the device alarms the alarm.

    4. Check the following function:

    The device will alarm when first people swipe the card when second people doesn’t.

    5. The automatic delay function:

    prevent people not hitting.

    6. Various control functions:

    By set the setting, the brake machine can be set at special time to be a regular open mode.

    7. The mode of choice:

    To meet the different requirements, set up as a two-way credit/ one-way credit card/free pass.

    8. Various control functions:

    external button, remote control, bar code, IC or ID card, etc.

    Tripod Turnstile Access Control System 11

    Product Technical Parameters

    Model NumberMR TT356SQ
    Product nameTripod Turnstile
    ApplicationSecurity Access Control Management
    Material304 stainless steel
    Power supplyAC 220V/110V 10% 50/60MHZ(optional)
    Warranty1 year
    KeyboardTripod Turnstile steel
    Working environmentTemperature: -10~+60
    Typefull automatic or semi automatic
    PASS SPEED30-40 Persons/min
    Material304 Stainless steel
    Drive voltageDC24V
    Lane width<_610mm
    Net weight50kg
    Access speed40 people/min
    Open Close speed0.2sec
    Rotating DirectionalSingle and Double adjustable
    SignalDry contract
    Working environmentIndoor outdoor
    Temperature-25 C –70 C
    Relative humidity<90% no condensation

    Tripod Turnstile Access Control System

    Optional Access Control Solutions:

    The turnstile gate can work with RFID Card, QR code, Barcode, ESD Tester. Thermometer Recognition, Face recognition, Fingerprint, Password Recognition, and other attendance device solutions.

    Occasion Application:

    suitable for commercial buildings, schools, GYM fitness centers or clubs, subways, airports, metro stations, IT Centre, office, college, term parts, institutions, clubs, and other high-end places related to entrance access control solutions.


    Can this swing barrier gate wiyh anti-tailaing alarm?

    yes, Anti-alarm is our standard request.

    What is the using lif of this speed gate?

    More than 5,000,000 times.

    Can I using our own access system to control the swing barrier gate?

    Yes, the swing turnstile gate can receive the signal from your access control system and running.

    Can you offeraccess control system?

    Yes, we have our access control system like rfid cards, QR codes, Barcode. Ticket selling systems, face recognition. ect.

    Can you make my own brand?

    Yes, we have 12 ODM Experience since 2009. we can make our private design and logo.

    What is the warranty policy?

    During 12 months warranty period. any parts running wrong or problems, we will send the free to replace.
