Electronic Lock
Security Electric Magnetic Door Rim Lock With Key
The Advanced electric lock comes in variety of models to suit various entry and exit applications. Mounting brackets form an integral part in installation of magnetic locks to both in-swing and out-swing doors
Security Electric Magnetic Door Rim Lock With Key
| Notice | If you want to place an order, please contact the seller, we will calculate the cheapest freight for you! |
All entrance doors should be unlocked by access control card or remote control which support long-distance high-speed card reading within external dual reader card. It can be used for both in-swinging and out-swinging doors. For In-swinging doors, the lock is usually installed at the opening corner of the door. For out-swinging door the lock is usually installed on the side of the door header. SS304 Stainless steel Electric RIM lock with double cylinder.
Double Electric Rim door lock Features:
Magnetic Lock has Security Electric Magnetic Door Rim Lock With Key features has listed below;
- High-strength stainless steel lock housing
- Elegant surface finish: stainless steel brushed
- Single Cylinder or Double Cylinder are available
- Solid brass ball latch
- Solid brass cylinder and deadbolt
- Reversible deadbolt
- Fail secure, pulse to open
- Reliable locking mechanism (Up to 1000000 operations)
- High security, low noise
Specification of Automatic Security Electric Magnetic Door Rim Lock With Key:
| Parameter | Description |
| Model | ER-D2; ER-S1 |
| Cylinder | Single or Double cylinder |
| Finish | Stainless Steel Brushed |
| Lock Size | 148 x 107 x 60mm |
| Backset | 60mm |
| Keys | 3pcs |
| Thickness of the lock body and strike | 2.0mm |
| Voltage | 12V DC(plus) |
| Working Current | 3A |
| Consumption Power | 10W |
| Unlock time | Pulse to unlock, within 1sec |
| Service life | 1,000,000 times |
| Operating Temp | under 40ºC ∼ 50ºC |
| Notice | If you want to place an order, please contact the seller, we will calculate the cheapest freight for you! |
| Parameter | Description |
| Model | ER-D2; ER-S1 |
| Cylinder | Single or Double cylinder |
| Finish | Stainless Steel Brushed |
| Lock Size | 148 x 107 x 60mm |
| Backset | 60mm |
| Keys | 3pcs |
| Thickness of the lock body and strike | 2.0mm |
| Voltage | 12V DC(plus) |
| Working Current | 3A |
| Consumption Power | 10W |
| Unlock time | Pulse to unlock, within 1sec |
| Service life | 1,000,000 times |
| Operating Temp | under 40ºC ∼ 50ºC |
