Rapid Roller Shutter Doors
High-speed doors optimize the flow of traffic, improve room conditions, and save energy. The range includes both vertically and horizontally opening transparent doors with a flexible curtain. They are available in combination with sectional doors and rolling shutters, as well as with service-friendly spiral doors with smooth aluminum profiles. Rapid Roller Shutter Doors also come with a powerful frequency converter control (FU) as standard, which considerably extends the lifespan of the door’s working parts.
Our Rapid Roller Shutter Doors come in many different types. Some are great for cold storage and others are for warehouses. Whatever your needs might be. if you want a high-speed door that’s reliable and tough, then ultratough is the right option to go with. This roller shutter door will protect your product loads from high winds as well as keep the facility clean and not contaminated. When energy loss occurs, there are durable doors and last opening speeds as well as reliable operations to maintain the workflow.
Rapid Roller Shutter Doors are designed to open and close at high operating and reliability in a commercial and industrial/ storage setting, where maintaining controlled environments and airflow is a top priority. Choosing a suitable door needs very careful consideration, and it is important to know how to use them and their specific characteristics to determine the best design for your on-site needs.Â
Specification:
| Brand | MR TECH |
| Model No | MR-RSGD138 |
| Product Name | Rapid Shutter Door |
| Open Style | Roller Shutter |
| Material | Aluminum Alloy |
| Size | Various types of sizes Available Customer Requesting |
| Color | White, Black, Silver, and Costumer Requesting colors are Available |
| Surface Treatment | Hot-dip, Galvanized, Powder Coated |
| Width Min./Max. | W: 1000/ 9000mm |
| Height Min./Max. | H: 1000/8000mm Larger Dimension on request |
| Open Speed | 0.6m/s~1.8m/s [Adjustable] |
| Close Speed | 0.6m/s [Adjustable] |
| Standard Thickness of door panel | 44mm |
| Thermal insulation of door panel | K≤1.5W/(m²·K) |
| Finishing | Â Anodizing + organic coloring |
| Wind load resistance | 32m/s(≤12F) |
| Working Voltage/frequency | 380v/14a/50Hz |
| Opening/Closing speed | 0.8m/sec to 1.5m/sec with VFD |
| Opening Direction | Vertical |
| Drawing Design | According to Your request |
| Optional products | Manual, Semi-Automation, Automatic. |
| Application | Residential, Industrials, Commercial, etc. |
| Optional Accessories for Speed Shutter Door | Photo Sensor, Flashing Light, Bluetooth Controller, Wi-Fi mobile Access with ( Voice Command Through Google Assistant, Alexa, Siri ), RFID, Vehicle LOOP Detectors, Face Recognition, Bluetooth USB Port. |
Basic features of High-Speed Shutter:
- They operate faster than standard roller shutters or sectional doors.
- Most models will operate at an opening and closing speed of 1 second per 1000mm.
- Speed Shutter Door is also non-swinging doors that typically roll, fold, or slide into a canopy at the top.
- They facilitate easy and rapid access to and from environmentally – controlled buildings or rooms whilst minimizing temperature changesÂ
- Rapid Roller Shutter Doors are ideally suited to applications that include the mitigation against heat loss in warehouses or distributed centers.
- They can also be used to protect refrigerated rooms or other sensitive environments, such as food or pharmaceutical manufacturing.
- The door will pose a strengthened drivetrain; a strong but lightweight curtain usually constructed from either PVC (a cheaper option) or steel (a more expensive option), and a high-speed 3-phase power motor with built-in safety fallbacks, such as safety edging and photocells.
| Notice | If you want to place an order, please contact the seller, and we will calculate the cheapest freight for you! |
