High Quality Safety Brake Used for Roller Shutter Motor

High Quality Safety Brake Used for Roller Shutter Motor

A safety brake is a device that allows or stops the motion of an object, typically by applying pressure against one side. This braking system is essential to roller shutters to protect both people and property. Some larger doors have direct drive motors with integrated safety brakes.

Specifications:

Advantages of Safety Brake:

1. The safety arrester brakes can be used in all MRTECH roller shutters. It is designed to prevent accidents from the sudden descent of roller shutter which is most prevalent in the event of broken motor drive chains.
2. It works similarly to a shock absorber, where in the event the drive chain of a roller shutter is broken during operation, the downturn speed of the shutter increases very quickly and would be unsafe.
3. The safety arrester brake reacts immediately to absorb the sudden accelerated speed by stopping the roller shutter from descending further.
4. The safety arrester brake will return to standby position once the motor drive chain is properly re-connected to the gear. Users can then proceed to replace the faulty parts safety

Features of High Quality Safety Brake Used for Roller Shutter Motor:

Interia safety brake to suit lightweight garage doors, Window shutters, and entrance door shutters. Cast alloy housing machined to accept micro-switch cut-out (optional extra)

• Anti-drop safety brake intended for use on roller shutter doors and garage doors.
• Safety brakes arrest the shutter in the event of a critical failure.
• Maintenance-free unit.
• 22 RPM locking speed.
• 16.8 mm cloverleaf bore
• The brake can be supplied on its own or with a suitable shaft and disc assembly to suit octagonal or round barrels.
