12~24 volt DC Infrared Safety Beams for Swing Gates
Photoelectric sensors are readily present in everyday life. They help safely control the opening and closing of garage doors and gates, control elevators, open the doors at the grocery store, detect the winning cars at racing events, and so much more.
Specification:
| Brand | MR TECH |
| Model No | MR PC30M |
| Product Name | 12~24 volt DC Infrared Safety Beams for Swing Gates |
| Material | ABS and Plastic |
| Theory | Infrared Sensor |
| Voltage | 12-24V DC |
| Current | ≤40mA |
| Infra-Red Frequency | 1.92khz |
| Sensing Range | 10-15 Meters |
| Anti-Interference | ±5 Angle |
| Wavelength | 940nm |
| Temperature | -20ºC ∼ +50ºC |
| Power Rated | 30W |
| Sensing object | Sensing everything within the detecting range |
| Ip Class | IP55 |
| Adjustable Angle | 180º |
| Relay Contact Loading Capacity | 1A/ 30V DC |
| Installation Distance | ≤ 2 Meters |
| Package Includes | Safety Photocell Sensors |
| Function | Anti-Pinch, Anti-Theft, Opening Gate. |
| Application | Rolling Shutter, Automatic Gates, Retractable Awning, Boom barriers. |
| Optional Accessories for 12~24 volt DC Infrared Safety Beams | Gate Motors, Garage Doors, Boom Barriers, Glass Door, Rolling Shutter Operator, Safety Motors, Hydraulic Rising Bollards, Automatic Lifting Roadblocks, Hydraulic Spike Road Blockers, Tyre Killer, and Road Blockers.. |
Benefits of Infrared Photocell Gate Sensor:
- Single beam infrared sensor with the latest LED indicator light.
- Anti-glare up to 50,000 LUX, to avoid the impact of glare or car light.
- Sealed design to anti-rain, fog, dust, and other integrated weather.
- With high levels of Anti-RFI/ EMI capability.
- High-power transmitter, sensitivity surplus degree up to 90%.
- Adjustable beam interdiction period, to make it flexible and adaptable
Features of 12~24 volt DC Infrared Safety Beams:
- Long-distance and high-sensitivity
- Working volts is 12-24V DC/AC, NO/NC for your option
- It can anti strong sunlight
- It can support 180-degree rotation.
| Notice | If you want to place an order, please contact the seller, and we will calculate the cheapest freight for you! |
