Install Sliding Gate Electric Motor Gallery
Our Latest Projects
Automatic Sliding Gate And Italian Motor with Remote Control
Suitable For Residential And Commercial Applications. Sliding Gate Motors Weighing Upto 300kg – 5000 Kg each Leaf
A Complete Range for All your Residential and Commercial applications. Our MR series Automatic Sliding Gate And Italian Motors type Swing Gate opener operates with gates up to 20m wide and 5000kg per leaf weight and is designed to work even in cases of intense usage and demanding environmental conditions.
It is highly reliable, cost-effective, and maintenance-free
CLIENT
Kumaran Hospital
DESIGNER
MRTECH
4 Channel Wireless Transmitter Four Button RF Remote Control
Original price was: ₹1,750.00.₹1,558.00Current price is: ₹1,558.00.Pieces
PROJECT WITH DESCRIPTION EXAMPLE
Compact Design- all-rounders for a better quality of living
Automatic Sliding Gate with Motors Lower energy consumption, more convenience and scope for design, and lower installation costs. Our bespoke Roller Type Operator is the ideal solution for your modernization or new-build Gate
Are sliding gates safe?
- Powered automatic sliding gates do not move particularly quickly but they are heavy and therefore possess considerable momentum when in motion.
- For that reason, the gates must be designed as far as reasonably practicable to eliminate mechanical hazards.
- Iron: Iron gates are the traditional choice for many homeowners due to their strength and durability. …
- Steel: Steel gates are even stronger and more durable than iron. …
- Wood: Wooden gates add a touch of elegance and warmth to your home’s entrance.
Sliding Gate with Motors
| Input Voltage: | AC220V/110V |
| Model | MR SGMO800 |
| Working Voltage: | DC 24V |
| Ambient Temperature: | -50℃ ~+50℃ |
| Rating Power: | 115W * 2 |
| Gate Width (per wing): | ≤7M |
| Gate Weight (per wing): | 800kgs |
| Regular Components: | Sliding gate Motor 2 motors, 1 panel, 2 remote controllers |
| Optional parts: | IR sensor, storage battery, visual doorbell, card reader, fingerprint reader |
| Weight (kg): | 26 |
| Dimension (cm): | 45*35*32 |
Convenience
MR. Series Gear-type operators are smooth, quiet, and easy to operate. They provide you with numerous options to make things more convenient for you – such as radio-remote operation.
This gives you all the functions in the palm of your hand, Open, Stop, Close, And Single leaf opening, and compatible with an auto-identification system: Linked with a camera, card reader, etc., the opener can jointly achieve the purpose of safety and anti-theft, entry or exit
Basic functions:
- open up or close up in sequence
- Automatically stopping function against extra resistance
- Infrared protection interface
- back-up power supply interface
- operating time limit protection
- optional operation mode for single or dual-wing
- adjustable interval setting in sequent close-up
- adjustable operating time limit setting
- automatically stopping and running reversely against excessive resistance during closing-up
- interface for the card reader and underground detector
- adjustable time setting for the automatic close-up function
functions:
- Due to the number of moving parts, sliding gates tend to be noisier than swinging ones.
- Although this may not be a problem in the situation of perimeter fencing, it may be a concern when considering internal gates or access points close to offices or sleeping quarters, or in residential areas.
- The installation of floor tracks may not always be practical, and the floor tracks will require regular maintenance to keep them free of debris.
| Optional Accessories | Bluetooth controller, Wi-Fi mobile access Controller, RFID with Detector, Fingerprint, Vehicle LOOP Detectors, Face Recognition, Photocell sensor, Electrical Side lock and center Lock, Bluetooth USB Controller, Safety edge, and Safety Break system. |
FAQs
1. Which motor is used in sliding gate?
These gate motors come in two different variations – AC and DC. The major difference is that DC motors are used for small gates with solar power, and battery backup because AC motors are used in gates that are on the heavier side for their strength and longevity.
2. How does a sliding gate motor work?
Sliding gates are moved by a motor to which a protruding toothed cog is attached. This meshes with a rack mounted on the inside of the gate,
3. What is the most powerful sliding gate motor?
The Mr. Tech Commercial/Industrial sliding gate motor is not only one of the most powerful sliding gate motors on the market but also one of the fastest.
4. Which is better sliding gate or normal gate?
If space is limited or something is blocking the area around your access point, sliding gates may well be your best option.
Because they slide along the fence line, this style of gate takes up minimal space. It also allows vehicles and pedestrians to access the property safely and easily.
